I was testing out certificate access to logon to z/OS using pthread_secure_applid() services . It took a little while to get my program working, but once it was working I tried to be “customer like” rather than a simple Unit Test. The documentation is not very clear, but it does work.

You can create a RACF definition for the simple case

• For a certificate where the Subject Distinguished Name(DN) matches the definition’s Subject DN, then use userid xyz.
• For a certificate where part of the Subject DN matches the definitions Subject DN, then use userid ijklm.

These both default to using an APPLID OMVSAPPL

I wanted to say

• for application id ZZZ, if a certificate with this subject DN, then use userid TESTZ
• for application id YYY if a certificate with the same subject DN, then use userid TESTY

Topics covered n this post:

• How to set up your enterprise certificate
  • If you want to control certificate to userid mapping at an individual level
  • If you want to control certificate to userid mapping at the group level
• Define a certificate-to-user mapping (simple case)
  • Use a fully qualified Subject DN filter
  • Use a partially qualified Subject DN filter
• Define a certificate with mutliid mapping
  • Use an Issuer Distinguished Name
  • Use a Subject Distinguished Name
• Creating definitions
• Controlling access to the applid
• Problem I experienced

How to set up your enterprise certificates

If you want to control certificate to userid mapping, at an individual level

You can use the following, where SDN is the Subject Distinguished Name from the certificate,

RACDCERT MAP ID(....  ) SDN(...)

for each individual.

To remove access you just delete the profile (and refresh RACLIST).

You can also specify the Issuers Distinguished Name (IDN) so you refer to the correct certificate.

If you want to control certificate to userid mapping, at the group level

You can use a Subject DN filter. This may mean you need to define your Subject DN with Organisation Units(OU), as

• CN=COLIN,OU=TEST,O=MYORG
• CN=MARY,OU=SALES,O=MYORG

You can then have a filter SDN(‘OU=TEST,O=MYORG’) to allow just those in the OU=TEST group to logon, and sales people will not get access.

If you then want to prevent individuals from getting access you need to define a specific profile, and point it to a userid which can do nothing.

You could also have your certificates issued by different CA’s For example, have a certificate with an Issuer Distinguished Name(IDN) including the department name.

• Subject DN(CN=COLIN,OU=TEST,O=MYORG) Issuer DN(OU=TEST,OU=CA,O=MYORG)

and specify IDN(OU=TEST,OU=CA,O=MYORG).

Note: with this, if someone changes department, and moved from Sales to Test, they will need a new certificate.

Some people may require more than one certificate. For example someone who has normal access for their day to day job, and super powers for emergencies.

Note: In addition to getting access with a certificate you may still want to use a password.

Define a certificate to user mapping (simple case)

Use a fully qualified Subject DN filter

For example, a certificate has SDN CN=docec256.O=Doc.C=GB .

//COLRACF  JOB 1,MSGCLASS=H
//S1  EXEC PGM=IKJEFT01,REGION=0M
//STEPLIB  DD  DISP=SHR,DSN=SYS1.MIGLIB
//SYSPRINT DD SYSOUT=*
//SYSTSPRT DD SYSOUT=*
//SYSTSIN DD *

RACDCERT DELMAP(LABEL('CP'))  ID(COLIN)
RACDCERT MAP ID(COLIN  )  -
   SDNFILTER('CN=docec256.O=Doc.C=GB')                  -
   IDNFILTER('CN=SSCA256.OU=CA.O=DOC.C=GB')             -
   WITHLABEL('CP')
RACDCERT LISTMAP ID(COLIN)
SETROPTS RACLIST(DIGTNMAP, DIGTCRIT) REFRESH
/*

This uses both Subject Distinguished Name, and Issuer Distinguished Name. You can use either or both filters.

With this definition when I used openssl s_client to talk to my server application running on z/OS. When I specified the client certificate with the specified Subject DN and signer, I could use:

• AT-TLS, use BPX1IOC() and retrieve the userid. Internally this uses applid=OMVSAPPL
• do it myself
  • retrieve the certificate with the BPX1IOC() TTLS_QUERY_ONLY call;
  • use rc = pthread_security_applid_np( __CREATE_SECURITY_ENV,…. “OMVSAPPL”) passing the certificate and the applid OMVSAPPL

The code checks my the extracted userid (COLIN) has read access to the profile OMVSAPPL in class(APPL)) and, if it has access, it returns the userid to the application.

See below if you do not want to use applid OMVSAPPL

Use a partially qualified Subject DN filter

Instead of a fully qualified Subject DN, CN=docec256.O=Doc.C=GB. You can use a partially qualified DN, for example CN=docec256.O=Doc.C=GB. Any certificate which has a DN including O=Doc.C=GB will be accepted

RACDCERT DELMAP(LABEL('CPGEN'))  ID(ADCDF)
RACDCERT MAP ID(ADCDF  )  -
   SDNFILTER('O=Doc.C=GB')                  -
   WITHLABEL('CPGEN')
RACDCERT LISTMAP ID(ADCDF)
SETROPTS RACLIST(DIGTNMAP, DIGTCRIT) REFRESH

With this definition when I used openssl s_client to talk to my server application running on z/OS. When I specified the client certificate with the specified Issuer CN, it worked the same way as the simple case above.

The code checks my the user extracted userid (ADCDF) has read access to the profile OMVSAPPL in class(APPL)) and, if it has access, it returns the userid to the application.

Define a certificate with mutliid mapping

A specific Subject DN gets a different userid depending on the application id.

As above you can specify an Issuer Distinguished Name or a Subject Distinguished Name.

Use an Issuer Distinguished Name

Use an Issuer certificate, so any certificate issued by DN this will be covered.

I defined the profile for my Issuer CA certificate. The definition below says – any certificate issued by this CA.

RACDCERT DELMAP(LABEL('CPMULTI')) MULTIID

RACDCERT MULTIID MAP WITHLABEL('CPMULTI') TRUST -
  IDNFILTER('CN=SSCA256.OU=CA.O=DOC.C=GB')      -
  CRITERIA(ZZAPPLID=&APPLID)

Define which userid to use based on the CRITeria

RDEFINE DIGTCRIT ZZAPPLID=ZZZ  APPLDATA('ADCDZ')
RDEFINE DIGTCRIT ZZAPPLID=AAA  APPLDATA('ADCDF')

In my program I had

struct __certificate  ct;
ct.__cert_type = __CERT_X509;
char * pData = (char *)  ioc.TTLSi_BufferPtr;

ct.__cert_length = ...
ct.__cert_ptr    = ...;
rc = pthread_security_applid_np(__CREATE_SECURITY_ENV,
         __CERTIFICATE_IDENTITY,
         sizeof(ct),
         &ct,
         "",
         0,
        "AAA");

With this, the CRITERIA(ZZAPPLID=&APPLID) becomes CRITERIA(ZZAPPLID=AAA), which maps to CRITeria

RDEFINE DIGTCRIT ZZAPPLID=AAA  APPLDATA('ADCDF'),

and so maps to userid ADCDF.

When applid ZZZ was used instead of AAA, then

RDEFINE DIGTCRIT ZZAPPLID=AAA  APPLDATA('ADCDF')

AT-TLS only seems to be able to use the APPL OMVSAPPL (the default). I could not find a way of getting it to use an APPLID, so I had to use pthead_security_appl_np to be able to use an applid different from the default.

Use a subject DN

You can use an explicit Subject DN

 RACDCERT MULTIID MAP WITHLABEL('CPMULTIU') TRUST -
     SDNFILTER('CN=docecgen.O=Doc2.C=GB')            -
   CRITERIA(UAPPLID=&APPLID)

 RDEFINE DIGTCRIT UAPPLID=AAA  APPLDATA('ADCDA')
 RDEFINE DIGTCRIT UAPPLID=BBB  APPLDATA('ADCDB')

the userid used depending which APPLID was specified in my application.

I could use a subset of the the SDN

RACDCERT DELMAP(LABEL('CPMULTIU')) MULTIID
RDELETE DIGTCRIT APPLID=OMVSAPPL
RDELETE DIGTCRIT APPLID=ZZZ

RACDCERT MULTIID MAP WITHLABEL('CPMULTIU') TRUST -
    SDNFILTER('O=Doc2.C=GB')            -
  CRITERIA(UAPPLID=&APPLID)

RDEFINE DIGTCRIT UAPPLID=AAA  APPLDATA('ADCDD')
RDEFINE DIGTCRIT UAPPLID=BBB  APPLDATA('ADCDE')

Creating definitions

What the documentation does not say, is that you can have any keyword in the criteria, as long as the substitute value has a DIGTCRIT.

This means you can have

RACDCERT MULTIID MAP ...    CRITERIA(ZORK=&APPLID)

and have statements like

RDEFINE DIGTCRIT ZORK=AAA  APPLDATA('IBMUSER')

Controlling access to the applid

If there is a profile for the applid in CLASS(APPL) the userid will need read access to the profile.

If the profile is not defined, then anyone can use the profile.

Problem I experienced

ESRCH: errno 143 EDC5143I No such process. errno2 0be8044c

I got messages

ESRCH:The user ID provided as input is not defined to the security product or does not have an OMVS segment defined
pthread_s… rc = -1 errno 143 EDC5143I No such process. errno2 0be8044c

Where TSO BPXMTEXT 0be8044c gives

BPXPTSEC 01/05/18
JRNoCertforUser: There is no userid defined for this certificate. Action: Ensure the userid is known to the SAF service.

Cause 1:

I used an APPLID which did not have a criteria

I also got this when I used pthread_security_applid_np(…) with an an applid which did not have a matching RDEFINE DIGTCRIT

For example the following worked

• applid AAA and RDEFINE DIGTCRIT UAPPLID=AAA APPLDATA(‘ADCDA’)

when I used a different applid I got the “EDC5143I No such process. errno2 0be8044c” message, along with the following on the joblog.

ICH408I USER(COLIN ) GROUP(SYS1 ) NAME(COLIN PAICE )
DIGITAL CERTIFICATE IS NOT DEFINED. CERTIFICATE SERIAL NUMBER(027C)
SUBJECT(CN=docecgen.O=Doc2.C=GB) ISSUER(CN=SSCA256.OU=CA.O=DOC.C=GB).

Cause 2:

In the definitions I had the wrong case: c=GB and c=gb.

Cause 3:

NOTRUST was specified

RACDCERT MULTIID MAP WITHLABEL('CPMULTIU') noTRUST -
SDNFILTER('CN=docecgen.O=Doc2.C=GB') -
CRITERIA(UAPPLID=&APPLID)

This also had a message on the job log:

ICH408I USER(START1 ) GROUP(SYS1 ) NAME(####################)
DIGITAL CERTIFICATE DEFINED TO A RESERVED USER ID. CERTIFICATE SERIAL
NUMBER(027C) SUBJECT(CN=docecgen.O=Doc2.C=GB) ISSUER(CN=SSCA256.OU=C
A.O=DOC.C=GB).

Cause 4:

I had specified the certificate’s DN in Issuers DN. It should have been SDNFILTER(‘CN=rsarsa.O=cpwebuser.C=GB’)

EMVSSAFEXTRERR 163 EDC5163I SAF/RACF extract error. errno2 0be8081c

pthread_secuity_applid_np() rc = -1 errno 163 EDC5163I SAF/RACF extract error. errno2 0be8081c

TSO BPXMTEXT 0be8081c , just gives

BPXPTSEC 01/05/18

with no message description

Cause 1:

I got this when I used

RACDCERT MULTIID MAP WITHLABEL('CPMULTIU') TRUST -
    SDNFILTER('CN=docecgen.O=Doc2.C=GB')            -
  CRITERIA(UAPPLID=&APPLID)

and the SDNFILTER value was in upper case. When I corrected it (to the above) it worked.

It looks like certificate filter not found.

Cause 2:

I had a lower case keyword such as SDNFILTER(‘CN=docecgen.O=Doc2.c=GB’)

EMVSSAFEXTRERR 163 EDC5163I SAF/RACF extract error. errno2 0be80820

TSO BPXMTEXT 0be8082 gave

BPXPTSEC 01/05/18

and no other information.

I had

RACDCERT MULTIID MAP WITHLABEL('CPMULTIU') TRUST -
    SDNFILTER('CN=docecgen.O=Doc2.C=GB')            -
  CRITERIA(UAPPLID=&APPLID)

RDEFINE DIGTCRIT UAPPLID=ZZZ  APPLDATA('ADCDB')

and userid ADCDB had no access to the RACF resource class(APPL) ZZZ.

EMVSERR 157 EDC5157I An internal error has occurred. errno2 0be800fc.

TSO BPXMTEXT 0be800fc gave

BPXPTSEC 01/05/18
JRSAFNoUID: The user ID has no UID

Action: Create an OMVS segment with a UID.

Cause:

If I display the userid LU ADCDG OMVS it gave UID= NONE.

I had created this situation using ALU ADCDG OMVS(NOUID). I reset it back using tso ALU ADCDG OMVS(UID(990098)).
